Quotation Requirements



File Guidelines and General Information

All Gerber files received by Welsa will be protected for your designing rights.

If NDA required , please provide us !
To speed up time and avoiding any mistake in production. Please provide your PCB Gerber file and BOM with completed information and meet the following requirements.

  • File type by designing software (CAD) should be in Gerber RX-274-X format.

  • Units are either in English units (inch) or metric units (mm)

  • All aperture file(s) are required to be sent with the gerber files

  • Drill chart, board outline, trace/space information are required

  • For more accurate quotes please include a (ReadMe) that contains the following information :

    • List of every file name with a brief description

    • Layer stack up sequence

    • Impedance control requirement information (if required)

    • BOM file if assembly required

    • Mechanical drawing if box or cables assembly required



Required Engineering Data For PCBA

To help your development of products successfully move into the pilot run/mass production, we have specifically listed all items you should prepare in advance to save your precious time. For any questions, please feel free to contact us for consultation.



BOM in Digital File

1.   Combined SMT components (top side and bottom side) and DIP components in one BOM

      (please provide the rule to assign the part numbers and how to identify the parts on both sides).

2.   List SMT components (top side and bottom side) and DIP components in two separate BOMs

      (please provide the way to identify the parts on both sides).

3.   List SMT top side components, SMT bottom side components, and DIP components in three

      different BOMs.

      Digital Assembly coordinates file (CAD, .txt file)

Auxiliary data

1.   Discard board for profile setting (boards with scrapped important parts are preferable)

2.   Sample board(board with all components on it)

3.   Empty PCB

4.   Stencil

5.   Other notes

Precautions

1.   Please do not provide chip R/C in bulk or components in segment

2.   Please do not provide used IC.

Notes for PCB fabrication

Request data for PCB fabrication: board thickness, surface finish, board material, solder mask color, text color
